| System |
|
Main Processor
|
Dual-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Video & Audio |
|
IP Camera Input
|
4 channel |
|
Two-way Talk
|
1 channel Input,1 channel Output, RCA |
| Display |
|
Interface
|
1 HDMI, 1 VGA |
|
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split
|
1/4 |
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
|
Compression
|
H.264/MJPEG |
|
Resolution
|
1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480) & etc. |
|
Record Rate
|
80Mbps |
|
Bit Rate
|
48~8192kbps |
|
Record Mode
|
Manual, Schedule(Regular(Continuous), MD), Stop |
|
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection |
|
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, FTP, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Playback & Backup |
|
Sync Playback
|
1/4 |
|
Search Mode
|
Time/Date, MD & Exact search (accurate to second), Smart search |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network/Internal SATA burner |
| Network |
|
Ethernet
|
1RJ-45 port (10/100Mbps) |
|
Wireless Network
|
Built-in Wifi module, 2 WiFi Antenna |
|
Network Function
|
HTTP, TCP/IP, IPv4/IPv6, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPOE, DDNS, FTP, IP Search(Support Snappy IP camera, DVR, NVS and etc.), P2P |
|
Max User Access
|
128 users |
|
Smart Phone
|
iPhone, iPad, Android, Windows Phone |
| Storage |
|
Internal HDD
|
1 SATA port, up to 4TB |
| Auxiliary Interface |
|
USB
|
2 ports (1 Rear), USB2.0 |
| General |
|
Power Supply
|
DC12V/2A |
|
Power Consumption
|
NVR: 10W (without HDD) |
|
Working Environment
|
-10°C~+55°C/10%~90%RH/86~106kpa |
| Camera |
|
Image Sensor
|
1/3” 3Megapixel progressive scan CMOS |
|
Effective Pixels
|
2048(H)x1536(V) |
