| System |
|
Main Processor
|
Quad-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Display |
|
Interface
|
2 HDMI (1 HDMI up to 3840x2160, Different Source ), 1 VGA |
|
Resolution
|
3840x2160, 1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Multi-screen Display
|
1st screen:
16CH: 1/4/8/9/16
32CH: 1/4/8/9/16/25/36
64CH: 1/4/8/9/16/25/36
2nd screen: 1/4/8/9/16
|
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Video Detection and Alarm |
|
Trigger Events
|
Recording, PTZ, Tour, Alarm Out, Video Push, Email, FTP, Snapshot, Buzzer and Screen Tips |
|
Video Detection
|
Motion Detection, MD Zones: 396 (22 × 18), Video Loss and Tampering |
|
Alarm input
|
16 Channel, Low Level Effective, Green Terminal Interface |
|
Relay Output
|
6 Channel, NO/NC Programmable, Green Terminal Interface |
|
Tracking Trigger Event
|
N/A |
| Playback and Backup |
|
Sync Playback
|
1/4/9/16 |
|
Search Mode
|
Time /Date, Alarm, MD and Exact Search (accurate tosecond) |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
|
Backup Mode
|
USB Device/Network/Internal SATA burner/eSATA Device |
| Storage |
|
Internal HDD
|
4 SATA III Ports, up to 6TB capacity for each HDD |
|
HDD Mode
|
Single |
|
eSATA
|
1 eSATA port |
|
SAS
|
N/A |
| Auxiliary Interface |
|
Front Cover
|
N/A |
|
USB
|
3 ports (2 Rear USB3.0,1 Front USB2.0) |
|
RS232
|
1 Port, for PC Communication and Keyboard |
|
RS485
|
1 Port, for PTZ Control |
| Third-party Support |
|
Third-party Support
|
Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic, Pelco, Samsung, Sanyo, Sony, Videotec, and more |
