| System |
|
Main Processor
|
Intel® Core™ i3 Processors |
|
Operating System
|
Embedded LINUX |
|
Motherboard
|
Embedded Board (Support 7x24 operation)
|
|
Memory
|
2GB DDR3 (up to 8GB) |
|
Case
|
Hot-dipped galvanized sheet steel(1.2mm thickened), High-precise aluminum alloy slide, Patented pull-out rack design |
|
Fan
|
Dual ball screw bearing fan, MTBF>100,000h, support replacement during operation
|
|
Interface
|
Local GUI &WEB GUI
|
| Video & Audio |
|
Input
|
32ch@1080P/128ch@720P/128ch@D1 |
|
Transmission
|
32ch@1080P/128ch@720P/128ch@D1 |
|
Recording
|
32ch@1080P/128ch@720P/128ch@D1
|
|
Preview
|
8ch@1080P/16ch@720P/32ch@D1(Screen 1~2 )
+16ch@1080P/16ch@720P/16ch@D1(Screen 3~6) (Optional) |
|
Playback
|
4ch@1080P/9ch@720P/16ch@D1 (Screen 1) |
|
Recording Resolution
|
8Mp, 5Mp, 3Mp, 1080P, 720P, 960H, D1, CIF, QCIF, VGA |
|
Audio
|
1ch Mic in, 1/1ch audio in/out |
| Recording |
|
Recording Mode
|
Manual, Schedule(Regular(Continuous), MD(Video detection: Motion detection, Camera blank, Video loss), Alarm), Stop |
|
Alarm Recording
|
Video loss, Camera blank, Motion detection, External alarm |
|
Backup Mode
|
Network download / USB HDD/USB CD&DVD-RW / eSATA Device |
| Display |
|
Interface
|
6 HDMI, 1 VGA (Default: 2 HDMI+1 VGA ) |
|
Video Output
|
6 HDMI, or 1ch VGA(or built-in LCD) & 5ch HDMI sync video output (Default: 2 HDMI, or 1 VGA(or built-in LCD) & 1ch HDMI sync video output ) |
|
Multi-screen Display
|
The 1st screen: 1/4/8/9/16/25/36/64
The 2nd-6th screens: 4 |
|
Privacy Masking
|
4 customized zones for privacy masking for each area |
