| Camera |
|
Image Sensor
|
Three 1/2.8” 2Megapixel Exmor R CMOS |
|
Effective Pixels
|
4096(H)x832(V) |
|
RAM/ROM
|
1024MB/128MB
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
0.007Lux/F1.8( Color), 0Lux/F1.8(IR on) |
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 30m(98ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
8
|
| Lens |
|
Lens Type
|
Fixed |
|
Mount Type
|
Board-in |
|
Focal Length
|
3.6mm |
|
Max. Aperture
|
F1.8 |
|
Angle of View
|
H: 180˚, V:44˚ |
|
Optical Zoom
|
N/A |
|
Focus Control
|
Fixed |
|
Close Focus Distance
|
N/A |
| Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range
|
Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚ |
| Intelligence |
|
IVS (optional)
|
Tripwire, Intrusion, Object Abandoned/Missing |
|
Advanced Intelligent Functions
|
Face Detection, People Counting, Heat Map, E-PTZ |
| Video |
|
Compression
|
H.265/H.264 |
|
Streaming Capability
|
3 Streams |
|
Resolution
|
4096×832/3840×780/2560×520/1280x260/1024X208 |
|
Frame Rate
|
|
Main Stream
|
4096x832(1~25/30fps)
|
|
Sub Stream
|
1024X208 (1 ~ 25/30fps)
|
|
Third Stream
|
1280x260 (1 ~ 25/30fps)
|
|
Bit Rate Control
|
CBR/VBR |
|
Bit Rate
|
H.265: 4Kbps~ 10Mbps
H.264: 8Kbps~ 16Mbps |
|
Day/Night
|
Auto(ICR) / Color / B/W |
|
BLC Mode
|
BLC / HLC / WDR(120dB) |
|
White Balance
|
Auto/Natural/Street Lamp/Outdoor/Manual |
|
Gain Control
|
Auto/Manual |
|
Noise Reduction
|
3D DNR |
|
Motion Detetion
|
Off / On (4 Zone, Rectangle) |
|
Region of Interest
|
Off / On (4 Zone, Rectangle) |
|
Electronic Image Stabilization(EIS)
|
N/A |
|
Smart IR
|
Support |
|
Defog
|
N/A |
|
Digital Zoom
|
16x |
|
Flip
|
N/A |
|
Mirror
|
N/A |
|
Privacy Masking
|
Off / On (4 Area, Rectangle) |
