32/64 Channel 3U NVR

Model : NVR-1632RR , Model : NVR-1664RR

Up to 32/64 channel IP camera input
H.264/MJPEG dual codec decoding
Max 256Mbps incoming bandwidth
2HDMI/VGA/TV simultaneous video output
16 channel synchronous realtime preview, GRID interface
Support Multi-brand network cameras: Snappy, Arecont Vision, AXIS, Bosch, Brickcom, Canon, CP Plus, Dynacolor, Honeywell, Panasonic,Pelco, Samsung, Sanyo, Sony, Videosec, Vivotek and etc.
ONVIF Version 2.3 conformance
3D intelligent positioning with Snappy PTZ camera
Support 16 SATA HDDs up to 64TB, 1 eSATA port,4 USB2.0
Support RAID 0, RAID 1, RAID 5, RAID 6, RAID 10
Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

System
Main Processor	Dual-core embedded processor
Operating System	Embedded LINUX
Video & Audio
IP Camera Input	32 channel (NVR-1632RR) 64 channel (NVR-1664RR)
Two-way Talk	1 channel Input, 1 channel Output, BNC
Display
Interface	2 HDMI, 1 VGA, 1TV
Resolution	1920×1080, 1280×1024, 1280×720, 1024×768
Display Split	1/4/8/9/16/25/36 (NVR-1632RR) 1/4/8/9/16/25/36 (NVR-1664RR)
OSD	Camera title, Time, Video loss, Camera lock, Motion detection, Recording
Recording
Compression	H.264/MJPEG
Resolution	5Mp(2560× 1920)/3Mp(2048× 1536)/1080P(1920× 1080)/720P(1280× 720)/D1(704× 576/704× 480) & etc.
Record Rate	192Mbps
Bit Rate	48~ 8192kbps
Record Mode	Manual, Schedule(Regular(Continuous), MD, Alarm), Stop
Record Interval	1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec
Video Detection & Alarm
Trigger Events	Recording, PTZ, Tour, Alarm, Video Push, Email, FTP, Buzzer & Screen tips
Video Detection	Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank
Alarm Input	16 channel
Relay Output	6 channel

Playback & Backup
Sync Playback	1/4/8/16
Search Mode	Time/Date, Alarm, MD & Exact search (accurate to second), Smart search
Playback Function	Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom
Backup Mode	USB Device/eSATA Device/Internal SATA burner/Network
Network
Ethernet	2 RJ-45 ports(10/100/1000Mbps)
Network Function	HTTP, TCP/IP, IPv4/IPv6, UPnP, RTSP, UDP, SMTP, NTP, DHCP, DNS, IP Filter, PPPoE, DDNS, FTP, Alarm Server, IP Search(Support Snappy IP camera, DVR, NVS and etc.)
Max. User Access	128 users
Smart Phone	iPhone, iPad, Android
Storage
Internal HDD	16 SATA ports up to 64TB
External HDD	1 eSATA port
RAID	Raid 0/1/5/6/10
Auxiliary Interface
USB	4 ports (2 Rear), USB2.0
RS232	1 port, For PC communication & Keyboard
RS485	1 port, For PTZ control
General
Power Supply	AC 100V~240V, 50/60 Hz
Power Consumption	NVR: 75W (without HDD)
Working Environment	-10°C~+55°C/10%~90%RH/86~106kpa
Dimension(W×D×H)	3U, 448mm×513mm×133.2mm
Weight	10.5kg~11.5kg (without HDD)
