| Camera |
|
Image Sensor
|
1/3” 3Megapixel progressive CMOS |
|
Effective Pixels
|
2304(H) x1536(V) |
|
RAM/ROM
|
256MB/16MB |
|
Scanning System
|
Progressive
|
|
Minimum Illumination
|
0.1Lux/F1.4(Color), 0Lux/F1.4(IR on) |
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 60m(197ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
2
|
| Lens |
|
Lens Type
|
Motorized |
|
Mount Type
|
Board-in |
|
Focal Length
|
2.7mm~12mm |
|
Max. Aperture
|
F1.4 |
|
Angle of View
|
H:87°~29°, V:42°~15° |
|
Focus Control
|
Motorized |
|
Close Focus Distance
|
0.3m |
| Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range
|
Pan:0° ~360 ° ;Tilt:0° ~78° ;Rotation:0° ~360° |
| Video |
|
Compression
|
H.264+/H.264 |
|
Streaming Capability
|
2 Streams |
|
Resolution
|
3M(2688×1520)/3M(2304×1296)/
1080P(1920x1080)/1.3M(1280x960)/ 720P(1280×720)/D1(704×576/704×480) /CIF(352×288/352×240) |
|
Frame Rate
|
3M(1 ~ 20fps),D1/CIF(1 ~ 25/30fps)
|
|
Bit Rate Control
|
CBR/VBR |
|
Bit Rate
|
H264:24K ~ 8Mbps |
|
Day/Night
|
Auto(ICR) / Color / B/W |
|
BLC Mode
|
BLC / HLC / DWDR |
|
White Balance
|
Auto/Natural/Street Lamp/Outdoor/Manual |
|
Gain Control
|
Auto/Manual |
|
Noise Reduction
|
3D DNR |
|
Motion Detection
|
Off / On (4 Zone, Rectangle) |
|
Region of Interest
|
Off / On (4 Zone) |
|
Electronic Image Stabilization (EIS)
|
N/A |
|
Smart IR
|
Support |
|
Digital Zoom
|
16x |
|
Flip
|
0°/90°/180°/270° |
|
Mirror
|
Off / On |
|
Privacy Masking
|
Off / On (4 Area, Rectangle) |
