| System |
|
Main Processor
|
Dual-core embedded processor |
|
Operating System
|
Embedded LINUX |
| Video & Audio |
|
IP Camera Input
|
4 channel(NVR-14RC-4P), 8 channel(NVR-18RC-4P) |
|
Two-way Talk
|
1 channel Input,1 channel Output, RCA |
| Display |
|
Interface
|
1 HDMI, 1 VGA |
|
Resolution
|
1920×1080, 1280×1024, 1280×720, 1024×768 |
|
Display Split
|
1/4(NVR-14RC-4P), 1/4/8/9(NVR-18RC-4P) |
|
OSD
|
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
|
Compression
|
H.264/MJPEG |
|
Resolution
|
1080P(1920×1080)/720P(1280×720)/D1 (704×576/704×480) & etc. |
|
Record Rate
|
Max 56Mbps |
|
Bit Rate
|
48~ 8192kbps |
|
Record Mode
|
Manual, Schedule(Regular(Continuous), MD), Stop |
|
Record Interval
|
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection |
|
Trigger Events
|
Recording, PTZ, Tour, Video Push, Email, FTP, Buzzer & Screen tips |
|
Video Detection
|
Motion Detection, MD Zones: 396(22×18), Video Loss & Camera Blank |
| Playback & Backup |
|
Sync Playback
|
1/4(NVR-14RC-4P), 1/4/8(NVR-18RC-4P) |
|
Search Mode
|
Time/Date, Alarm, MD & Exact search (accurate to second), Smart search |
|
Playback Function
|
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
|
Backup Mode
|
USB Device/Network/Internal SATA burner |
