| System |
|
Power supply
|
2-400W
2-400W, 1+1 redundant, support online replacement |
|
Fan
|
Redundant two-ball bearing fans, MTBF＞100,000 hours，support online replacement |
|
Interface
|
2*SAS 2.0 wide port, rate:6Gbps |
|
Chassis
|
Conform to SBB2.0 |
|
Chassis management
|
SES protocol |
| HDD management |
|
Hard disk
|
16 SATAⅡHDDs, SAS HDDS(support 3TB, 4TB, 6TB) |
|
HDD install
|
Independent HDD holder, support hot-swap |
| General |
|
Power supply
|
100V-240V AC, 47-63Hz |
|
Power Consumption
|
≤200W (include HDD) |
|
Working temperature
|
0℃～40℃ |
|
Working Humidity
|
10%~80%(non-condensation) |
|
Storage Temperature
|
-20℃~70℃ |
|
Storage Humidity
|
5%~90%(non-condensation) |
|
Working Elevation
|
-60m～3000m |
|
Dimension(W×D×H)
|
133.2mm*448mm*490.4mm |
|
Weight(exclude HDD)
|
23kg |
|
Mounting
|
19 feet standard rack-mounted |
