| Camera |
|
Image Sensor
|
1/3” 4Megapixel progressive scan CMOS |
|
Effective Pixels
|
2688(H)x1520(V) |
|
RAM/ROM
|
512MB/32MB
|
|
Scanning System
|
Progressive
|
|
Min. Illumination
|
0.08Lux/F2.0 (Color), 0Lux/F2.0 (IR on) |
|
S/N Ratio
|
More than 50dB
|
|
IR Distance
|
Distance up to 30m (98.4ft)
|
|
IR On/Off Control
|
Auto/ Manual
|
|
IR LEDs
|
24
|
| Lens |
|
Lens Type
|
Fixed |
|
Mount Type
|
Board-in |
|
Focal Length
|
3.6mm (2.8mm, 6mm optional |
|
Max. Aperture
|
F2.0 (F2.0. F2.0)
|
|
Angle of View
|
H: 87° (104°, 55°), V: 48° (57°, 31°) |
|
Optical Zoom
|
N/A |
|
Focus Control
|
Fixed |
|
Close Focus Distance
|
N/A |
| Pan/Tilt/Rotation |
|
Pan/Tilt/Rotation Range
|
Pan:0˚~355˚; Tilt:0˚~64˚; Rotation:0˚~355˚ |
| Intelligence |
|
IVS (optional)
|
Tripwire, Intrusion, Object Abandoned/Missing |
|
Advanced Intelligent Functions
|
Face Detection |
| Video |
|
Compression
|
H.265+/H.265/H.264+/H.264 |
|
Streaming Capability
|
3 Streams |
|
Resolution
|
4M(2688x1520)/3M(2304x1296)/1080P(1920x1080)/1.3M(1280×960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240) |
|
Frame Rate
|
|
Main Stream
|
4M(1~25/30fps)
|
|
Sub Stream
|
D1(1~25/30fps)
|
|
Third Stream
|
720P(1~25/30fps)
|
|
Bit Rate Control
|
CBR/VBR |
|
Bit Rate
|
H.264: 24~10240Kbps , H.265: 14~9984Kbps |
|
Day/Night
|
Auto(ICR) / Color / B/W |
|
BLC Mode
|
BLC / HLC / WDR(120dB) |
|
White Balance
|
Auto/Natural/Street Lamp/Outdoor/Manual |
|
Gain Control
|
Auto/Manual |
|
Noise Reduction
|
3D DNR |
|
Motion Detetion
|
Off / On (4 Zone, Rectangle) |
|
Region of Interest
|
Off / On (4 Zone) |
|
Electronic Image Stabilization (EIS)
|
N/A |
|
Smart IR
|
Support |
|
Defog
|
N/A |
|
Digital Zoom
|
16x |
|
Flip
|
0°/90°/180°/270° |
|
Mirror
|
Off / On |
|
Privacy Masking
|
Off / On (4 Area, Rectangle) |
